4 Wavelength, High-Powered, Diode Laser Hair Removal Machine
The EternaQUAD range is not like your typical diode laser hair removal machine. It is the next evolution of technology for skin and hair analysis and effective treatment delivery.
AI Technology: we are introducing an AI-based analysis handset which detects hair colour, thickness, density and skin type. It then takes this data and automatically uploads it to give you the best baseline settings for an effective treatment.
Here are some of the amazing features of the EternaQUAD:
- AI skin analysis handset
- German-designed LIMO Lenses
- 3 attachable treatment lenses in varying sizes
- 4 wavelengths of laser output
- Ergonomic handset with new strain relief
EternaQUAD – modernising laser hair removal machines.
EternaQUAD - 4 Wavelength Diode
What’s the difference between a single or Quad wavelength for hair removal?
While the 808nm single-wavelength diode laser is a reliable and effective option for hair removal, the 4-wavelength diode laser offers enhanced versatility and efficacy, particularly for a broader range of skin types and hair characteristics.
The 4-wavelength system is likely to provide better overall results with fewer side effects, making it a preferred choice for many practitioners.
1 Wavelength 808nm Diode Laser
Mechanism and Use: The 808nm diode laser is highly effective in targeting melanin in the hair follicle, making it particularly suitable for hair removal. Its longer wavelength allows deeper penetration into the skin, making it effective for all skin types, including darker skin tones.
Safety and Efficacy: The 808nm wavelength is known for its balance between efficacy and safety, offering effective hair reduction with a lower risk of side effects such as pigmentation changes or burns. This laser works well on both lighter and darker skin types but requires multiple treatments for optimal results.
Pain and Side Effects: The 808nm laser is generally well-tolerated, though some patients may experience mild pain, erythema, or swelling post-treatment. Side effects tend to be transient and manageable.
4-Wavelength Diode Laser
Mechanism and Versatility: A 4-wavelength diode laser typically combines wavelengths such as 755nm, 808nm, 940nm, and 1060nm. This combination allows the laser to target hair follicles at different depths and with varying absorption rates, making it highly versatile and effective for a broader range of hair types and skin tones.
Efficacy and Results: The combination of multiple wavelengths enhances the overall efficacy of hair removal, particularly in challenging cases such as fine or lighter hair and darker skin. Studies have shown superior hair reduction results when compared to single-wavelength systems, particularly in more diverse skin types.
Patient Comfort and Side Effects: The use of multiple wavelengths may reduce the risk of adverse effects because it allows the use of lower fluences across each wavelength. This can lead to a more comfortable treatment experience with less pain and reduced risk of hyperpigmentation, especially in patients with darker skin.
Versatile Diode Laser Hair Removal
Customisable Head Sizes for Precision and Speed – EternaQUAD PRO
Introducing EternaQUAD PRO diode laser hair removal handset, designed with versatility in mind. Whether targeting small, precise areas or covering larger surfaces, this device features three interchangeable head sizes tailored to your needs.
The small head is perfect for facial hair and other delicate areas, the medium head offers great coverage for underarms and bikini lines, while the large head ensures fast treatment for larger areas like legs.
Achieve smooth, hair-free skin effortlessly with the EternaQUAD PRO handset that adapts to you.
15 x 15mm - Optical Lens
The medium attachment is perfect for areas such as the underarms, bikini line, and smaller patches of skin, balancing speed and accuracy for efficient treatments.
30 x 15mm - Optical Lens
For larger surfaces like the legs, arms, or back, the large attachment covers more area in less time, making the process quick and easy.
8 x 8mm - Optical Lens
The small attachment is ideal for precision work on delicate areas like the upper lip, eyebrow shaping, or other facial regions, offering targeted application without compromising comfort.
New Technology - Better Efficacy
LIMO Lenses are now available with EternaQUAD Diode Laser Hair Removal
The EternaQUAD’s LIMO Lens fast-axis collimator is an optical component specifically designed for high-power diode laser systems, such as those used in laser hair removal.
Diode lasers typically emit light that is highly divergent along two axes (fast and slow axis), meaning the laser beam spreads out unevenly. The fast-axis collimator (FAC) is designed to minimise this divergence along the fast axis, producing a more focused and precise beam.
In the context of diode laser hair removal:
- Precision: The LIMO Lens FAC helps concentrate the laser energy into a tight, uniform beam, improving the accuracy of targeting hair follicles without damaging the surrounding skin.
- Efficiency: Collimating the beam effectively enhances the laser’s energy transfer, making the treatment faster and more effective.
- Cooling: The use of a LIMO Lens fast-axis collimator can also help in reducing heat buildup in the device, which improves both safety and comfort during the procedure.
In essence, this type of lens improves the performance of the laser for hair removal treatments by ensuring a more focused beam and increasing overall efficiency.
Professional – Diode Laser Hair Removal Machine
The EternaQUAD PRO is the next evolution in diode laser hair removal treatments. Using modern 4-wavelengths and an AI-based skin analysis hair removal is simpler than ever.
Designed for professionals who seek simple operation and setup with professional hair removal results.
EternaQUAD PRO uses state-of-the-art design and advanced features, this product represents a significant leap forward, setting new standards in hair removal efficiency and comfort.
Technical Specification
Laser Type
Output Wavelengths
Peak Power Output
Spot Size
Maximum Handset Shots
Typical Handset Shots
Fluence
Pulse Duration
Frequency
Cooling System
Handset Cooling Temp
Diode Laser – For Hair Reduction/Removal
755, 808, 940 and 1064nm
2000W
15x15mm, 15x30mm & 8mm Interchangeable
80 Million Shots
40 Million Shots
2-50 J/cm2 Adjustable
10-400ms Adjustable
1-10 Hz Adjustable
Air to Liquid Heat Exchange, Double thermo-electric Radiator
-10 / -5oC
Diode Laser Hair Removal Machine
This cutting-edge 4 wavelength diode laser is set to transform the beauty industry with it’s unparalleled precision and effectiveness.
Engineered for those who seek the best in aesthetic solutions, EternaQUAD offers a groundbreaking approach to achieving smooth, hair-free skin.
With its state-of-the-art design and advanced features, this product represents a significant leap forward, setting new standards in hair removal efficiency and comfort.
Technical Specification
Laser Type
Output Wavelengths
Peak Power Output
Spot Size
Maximum Handset Shots
Typical Handset Shots
Fluence
Pulse Duration
Frequency
Cooling System
Handset Cooling Temp
Diode Laser – For Hair Reduction/Removal
755, 808, 940 and 1064nm
1200W
15x15mm / 15x30mm
80 Million Shots
40 Million Shots
1-45 J/cm2 Adjustable
10-200ms Adjustable
1-15 Hz Adjustable
Air to Liquid Heat Exchange, Double thermo-electric Radiator
-10 / +5oC
